Range New Unica Device application Power supply Product or component type Socket-outlet Device presentation Mechanism Socket number : 1 Outlet poles configuration : 2P Outlet standard : Euroamerican Complementary Cover type : With shutter Device mounting : Flush Rated current : 16 A [Ue] rated operational voltage : 250 V Network type : AC Network frequency : 50/60 Hz Number of modules : 1 module Fixing mode : Clip-in Colour tint : White
Range New Unica Device application Power supply Product or component type Socket-outlet Device presentation Mechanism Socket number : 1 Outlet poles configuration : 2P Outlet standard : Euroamerican Complementary Cover type : With shutter Device mounting : Flush Rated current : 16 A [Ue] rated operational voltage : 250 V Network type : AC Network frequency : 50/60 Hz Number of modules : 1 module Fixing mode : Clip-in Colour tint : White Connections - terminals : Screw terminals Cable cross section - 0…4 mm² cable(s), 2 - cable stiffness: flexible - 0…4 mm² - cable stiffness: rigid Minimum load breaking capacity : 100 operations 1.25 In and 1.1 Un, cos phi = 0.6 Electrical durability : 10000 cycles, cos phi = 0.8 Insulation resistance : > 5 MOhm at 500 V Dielectric strength : 2000 V Material:. -PC: mechanism cover -PC (polycarbonate) GF10 FR: casing Surface finish: Glossy Embedding depth 24 mm Depth 35.5 mm Width 22.5 mm Height 45 mm Net weight 0.0193 kg
