Range : Miluz Product Type : Switch Device Presentation : Module Device Mounting : Flush Switch Function : 1-way Ambient Air Temperature For Operation : -5…40 °C
Number Of Rocker : 2 Local Signalling : Without pilot light Rated Current : 10 AX [Ue] Rated Operational Voltage : 250 V AC Load Type : Resistive load : 100 W Fluorescent load Inductive lamp Material : PC (polycarbonate): actuator PC (polycarbonate): dolly PC (polycarbonate): base cover PC (polycarbonate): base Brass and copper alloy: terminals Silver alloy : contact Number Of Modules : 1 module Fixing Mode : Click-in Connections - Terminals : Screw-clamp terminals Wire Stripping Length : 12.0 mm Dimensions : H 45 X W 22.25 X D 33.37 mm Projecting Depth : 21.3 mm Ip Degree Of Protection IP20
