Features : ■ Damping technology with hidden micro-damper. ■ Available cup with 48 mm drilling pattern. ■ Cup diameter 35 mm ■ Steel mounting plate, vertical adjustment by CAM; 37x32 pattern. ■ Frontal adjustment BY CAM - 0/+5 mm. ■ Lateral overlay adjustment -1/+5 mm. ■ In addition to vertical adjustment on mounting plate.
Technical details Door type : Standard door / wooden door furniture. User friendly features : Soft closing feature. Door mounting option : inset. Opening angle : 105°, or 90° with LIMITER ( separate accessory ). Max. door thickness : 24 mm. Available cup : 48 mm drilling pattern. Cup diameter : 35 mm. Cup depth : 11.4 mm. Mounting plate : Steel , with vertical adjustment. Type of installation : for screwing on. Material : Steel. Finish : galvanic Anthracite.
** Optional : LIMITER, This accessory is used to limit the opening of the door to 90°.Easily inserted into hinges with 105° opening.CODE 046399025 order separately.
